Author
|
Message |
|
|
 Posted: Sat Mar 29, 2014 1:23 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
 |
Long Chat with Charlie yesterday regarding the new engine... here are his plans.
Newman or Piper 300 cams
Solid lifters
lash caps
Bigger valves
Knife edged crank
Billet steel flywheel
The idea is to build a reliable and strong engine that is capable of revving to 9000rpm. The power needs to be between 4000 and 8000rpm. The targets are. 250BHP and 220Nm of torque with a nice flat torque curve to suit the Sadev sequential box. The engine should still be ready for FCS after mapping at Mtech in Wiltshire.
| |  |
|
|
 |
Last edited by macj on Sun May 25, 2014 9:59 am; edited 1 time in total
|
|
|
|
|
|
|
Posted: Sat Mar 29, 2014 1:26 pm |
|
|
|
|
Joined: Mar 22, 2012
Posts: 235
Trade Rating: 0
Location: ireland
|
|
Mental!!The car will be awesome
| | |
|
|
|
|
 | |  |
|
2000 gti 138,tein superstreet coilovers front,tein adjustable shocks rear,22mm rear arb,carbon fibre strut brace, 6 point omp cage,fibre glass bonnet,polycarb windows,406 v6 brembo 4 pots,carbon Lorraine rc6 pads,brembo 307hdi front discs,406 v6 master cylinder,braided hoses all round,306 gti-6 brake reservoir,abs removed,4.9 cwp with 3j driveline plated lsd,compbrake quickshift,k&n filter with cold air feed pipe,4 branch mani,decat,sportex straight thru race system,mocal oil cooler,group n engine mounts,omp bucket seats,omp steering wheel,battery relocated to boot,4 point harnesses,15'team dynamics pro race 1.2 on Michelin slicks | |
 | |  |
|
|
|
|
|
|
|
Posted: Sat Mar 29, 2014 1:28 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
Lets hope so...... cant wait for the sequential box...... wont be built and fitted till Autumn
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Sun Mar 30, 2014 4:06 am |
|
|
|
|
Joined: Jun 04, 2010
Posts: 1691
Trade Rating: +3
Location: northallerton
|
|
is this a new engine or more mods to the origional, how much more can you get lol
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Sun Mar 30, 2014 12:33 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
This will be a vitually new engine. only the head, pistons, rods and crank will be from the old unit.... even the crank could get the chop if its worn or fails the crack test.
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Mon Mar 31, 2014 4:32 pm |
|
|
|
|
Joined: Feb 08, 2010
Posts: 901
Trade Rating: +1
Location: Istanbul / Turkey
|
|
Be careful with oil pump. It can be explode at 9000 rpm. Lots of French guys know this problem. My GTI180 Turbo friend lost oil pump 2 times.
| | |
|
|
|
|
| | |
| 2005 206 RC RED
Bilstein B14 Coilover / Brembo 4 Pot Front 330x28 - Rear 325x8 / Quaife ATB Limited Slip Diff / Janspeed Catback
Lot's of CNC machined customs pars. | |
| | |
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 12:44 am |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
Thank Schumi.... how did they get round the problem
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 2:26 pm |
|
|
|
|
Joined: Feb 08, 2010
Posts: 901
Trade Rating: +1
Location: Istanbul / Turkey
|
|
They are using French Engine Specialist RDM companys oil pump. But they dont supply any part. Just turn key complete engines. Best EW engine come from RDM. Some second hand oil pumps on sale. But no one open and take picture from inside. What is upgraded. Also xrallyparts can supply oil pump but nearly 900 euro.
Peugeot 207 S2000 with EW10J4S also using wet sump as same as our engines. But that oil pump almost 2500 €. I will gone to dry sump setup.
This company sell dry sump setups. Thats a really solutions. Also lower height oil pan give much more clearance for safety at rally stages. Never oil surge on any corner or condition. But price to much. I cant remember how much. I ask last year.
www.a-e.dk/Motor-51115
| | |
|
|
|
|
| | |
| 2005 206 RC RED
Bilstein B14 Coilover / Brembo 4 Pot Front 330x28 - Rear 325x8 / Quaife ATB Limited Slip Diff / Janspeed Catback
Lot's of CNC machined customs pars. | |
| | |
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 3:36 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
The pump and tank I have already but I cant find a dry sump pan for EW10J4 engine
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 3:39 pm |
|
|
|
|
Joined: Feb 08, 2010
Posts: 7045
Trade Rating: +5
Location: In the garage
|
|
I heard that Longman always fitted the EW12 pump to their engines...dunno why.
| | |
|
|
|
|
| | |
| 2001 GTi 138, Bilstein Sprint dampers, H&R springs, 21mm Peugeot Sport torsion bars, 22mm rear ARB, Peugeot Sport Group A wishbones, 283mm discs, Goodridge stainless hoses, Maniflow 304 grade 4-2-1 2.5" manifold and system, 200 cell cat, Richard Longman head, 45mm Jenvey throttle bodies, 9.5mm TB spacers, 90mm air horns, Jenvey throttle linkage, Jenvey fuel rail, Aeromotive and Goodridge fuel fittings and braided hose, ITG sausage filter, Radtec custom radiator, Piper Ultimate Road cams, Piper vernier pulleys, Omex 600 ECU. Saxo electric PAS pump, Vibra Technics engine mounts. Samco coolant hoses, TTV steel flywheel, 4.76 final drive ratio, 307 CC 180 ratios. 2019 BMW 530i. 2017 Mercedes C300 convertible. | |
| | |
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 3:57 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
would it be a slightly higher capacity or flow rate. I know that changing the spring rate increases a 137 pressure no problem
I might pull one to bits and have a look
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Tue Apr 01, 2014 5:26 pm |
|
|
|
|
Joined: Feb 08, 2010
Posts: 901
Trade Rating: +1
Location: Istanbul / Turkey
|
|
| Edward wrote: |
| I heard that Longman always fitted the EW12 pump to their engines...dunno why. |
Thats true but non of engine builders dont know why he used EW12 one. Because there is no difference. Even Sandy Brown cant find why.
| | |
|
|
|
|
| | |
| 2005 206 RC RED
Bilstein B14 Coilover / Brembo 4 Pot Front 330x28 - Rear 325x8 / Quaife ATB Limited Slip Diff / Janspeed Catback
Lot's of CNC machined customs pars. | |
| | |
|
|
|
|
|
|
|
Posted: Sun Apr 06, 2014 3:57 pm |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
|
|
|
|
|
|
|
|
|
Posted: Mon Apr 21, 2014 8:35 am |
|
|
|
|
Joined: May 21, 2013
Posts: 60
Trade Rating: 0
Location: Oxfordshire
|
|
Any joy finding a sump pan? I've been looking for a dry sump kit as well but no joy. I emailed the company Alternative Engineering as linked above by Schumi but they no longer sell the kits.
| | |
|
|
|
|
|
|
|
|
|
|
Posted: Mon Apr 21, 2014 10:32 am |
|
|
|
|
Joined: Feb 07, 2010
Posts: 3085
Trade Rating: +12
Location: Essex
|
|
I am looking a modding a standard sump pan. The idea being that you can cut out the majority of the ali pan and get a new plate welded in the bottom. Only problem would be distortion, meaning I would need to get the face skimmed
| | |
|
|
|
|
|
|
|
|
